Connecting autonomous vehicles and smart level crossings: The future of incident prevention

Posted: 23 March 2022 | | No comments yet

Connected vehicles are becoming commonplace on the road and are increasingly moving towards more automation. In 2017, the SNCF Innovation and Research Department developed a project to transform level crossings into a crossroads connected with road vehicles. Building upon the results of this project, SNCF started a new challenge in partnership with Valeo. Virginie Taillandier, Project Manager of Connected Level Crossings at SNCF, explores how this partnership is working to prepare and secure level crossings for the advent of autonomous and automated vehicles.

While autonomous or automated vehicles may seem in the realm of science fiction, many cars, such as Tesla vehicles, are already offering a first level of automation that allow drivers to delegate control of speed and direction. Currently, drivers must still monitor the environment and regain control if necessary. However, several car manufacturers have announced the upcoming release of vehicles offering a greater range of automation, which will allow the car to analyse its surroundings and act accordingly.

A level crossing is an intersection between a railway and a road. 99 per cent of accidents at level crossings are due to a violation of traffic rules; it is the third leading cause of railway fatalities.

In 2017, SNCF’s Innovation and Research Department launched a technological renewal project to transform the level crossing into a crossroads connected with road vehicles. In 2018, the development of a prototype demonstrated that level crossings can play a key role in the Cooperative Intelligent Transport System (C-ITS) ecosystem.

In 2019, SNCF joined the C-Roads project as an associated partner. The level crossing was integrated into the C-ITS architecture (see Figure 1) with hybrid communication in 5G (Wi-Fi) and 4G (cellular). The goal was to send messages on the level crossing status (closed, open, works in progress, out of order) and its characteristics (limitation of height, width, weight, speed or ground) to vehicles (V2X).

Validation tests were carried out in 2019 and 2020 on a level crossing located in Brittany including the national and European partners of the C-Roads project.

A new challenge appeared in 2020 with autonomous/automated vehicles. Our belief was that autonomous/automated vehicles could further reduce the number of accidents at level crossings, this conviction led to the setting-up of the HERMES project.

The HERMES project is a partnership between SNCF and Valeo, combining rail and automotive expertise. There are two objectives of the HERMES project, to prepare level crossings for the arrival of autonomous vehicles and to prepare the automotive world by taking level crossings into account as a use case on the roads.

c-roads

Figure 1: C-Roads project architecture



What is an autonomous vehicle?

An autonomous vehicle is a road vehicle able to drive without the active intervention of a human being, due to numerous sensors and to a software system of calculation or on-board artificial intelligence. The Society of Automotive Engineers (SAE) has declared there to be six levels of automation.

For a few years, road regulation began to change in the world. At the end of 2020, the Japanese authorities authorised the Honda Legend 3 for the market, it had had autonomous driving level 3. Through the recent ordinances of the mobility law, published in April 2021, France became the first European country to adapt the road and transport codes to allow the circulation on the road of autonomous and automated vehicles from September 2022, as long as vehicles are approved.

In the HERMES project we chose to focus on levels 3 and 4.

HERMES project methodology

The project began in 2020 by producing a taxonomy of level crossings in France, i.e., describing the equipment and their characteristics, allowing the autonomous/automated vehicles to identify a level crossing (signs, lights, barriers), as well as the existing road configurations. Thus, from these elements, the autonomous vehicle can distinguish what it encounters on its road.

An initial Preliminary Hazard Analysis (PHA) has been conducted to identify the hazardous behaviours of the automated driving system ADS (called undesired events).

v2x

Figure 2: V2X connectivity.

Then three different types of dependability studies have been done in parallel: a functional safety study, a safety of the intended functionality (SOTIF) study and a cyber-security study. The goals were to identify and evaluate risks due to hazardous behaviours of the ADS caused by (respectively) random hardware failures, performance limitations, cyber-attacks/malicious human behaviours and to define countermeasures that allow to reduce such risks at a reasonable level. A focus was done in this project on the hazardous behaviours due to dysfunctions of the ADS perception of road and level crossing. The methodology framework used for these three studies are based on (respectively) ISO 26262, ISO 21448 and ISO 21434.

A conciliation phase was then carried out between the three types of countermeasures, to ensure that they were consistent/not contradictory/complementary between each other.

Demonstrations

The demonstrations took place in 2021 at the level crossing n°449 in Brec’h (in Brittany, France), which is an active level crossing equipped with flashing lights and two half-barriers.

The level crossing management system was connected to a Roadside Unit (RSU), in charge of sending information about the level crossing area (V2X messages) to the automated vehicle, via a wireless communication (V2X communication), standardised according to the ETSI ITS communication protocol stack.

figure3

Figure 3: Scenario 1

The automated vehicle was also equipped with V2X connectivity (see Figure 2) and could particularly detect the level crossing by using its exteroceptive sensors (e.g., camera) and a digital map in addition of such V2X link.

During the demonstrations, several scenarios were carried out to test the nominal modes and degraded modes of the two systems, including:

  • The vehicle autonomously crosses the open level crossing
  • If the level crossing is closed, the vehicle stops at the level crossing entry, And the vehicle waits until the complete reopening of the barriers before crossing
  • If the vehicle is not in capacity to cross the level crossing, the vehicle requests the driver to take back control. If the driver does not respond within the allotted time (10 seconds during the demonstration), the vehicle is stopped before the level crossing (see Figure 3, Scenario 1)
  • With traffic jams, when approaching an open level crossing, the autonomous vehicle will stop and wait for the level crossing area to be completely clear before entering (see Figure 4, Scenarios 2 and 3)
  • If an obstacle is detected on the railway track, the vehicle will stop upstream and not enter the dangerous zone of the railway area.

The target scenarios have been fulfilled by the automated vehicle, with the expected performance in terms of functionality and safety (i.e. no hazardous behaviour). In particular, the assistance brought by the level crossing, via the V2X communication link, turns out to be especially useful to ensure the redundancy of the level crossing perception.

figure 4

Figure 4: Scenarios 2 and 3

Conclusion

These tests enabled us to validate the various assumptions made between SNCF and Valeo, particularly in terms of functional safety and cyber-security.

The challenges for SNCF consist of achieving the standardisation at European level of level crossing use cases but also in creating the criteria capacity of vehicles to cross a level crossing in the approval of autonomous/automated vehicles.

This is a new opportunity for SNCF to shine internationally beyond its rail perimeter so that the subject of level crossing safety is considered by the automotive and road sectors.

Virginie TaillandierVirginie Taillandier has a master’s degree in marketing. She has overseen the Tech4Rail Level Crossing project in the Innovation and Research Department of SNCF since 2017. She has been a national level crossing expert for five years at the Safety and Security Department of SNCF Réseau. She started her career in 2015 in the rail transport sector and worked at different positions related to security and safety at RATP (Parisian Metro and Suburban transport). She also worked in the domain of information systems in the car industry in 2010.
