Catenary free operation of trams – topology and operational concept

For tram networks that operate via overhead lines, difficult building conditions and harming the cityscape can lead to unwanted high construction costs and lack of acceptance from citizens and town planners. To avoid these, the use of a tram with energy storage that enables catenary free operation (CFO) could be a more cost-effective solution and provide the necessary acceptance. Frank Becker, System Engineer in the Propulsion & Controls Division at Bombardier Transportation, presents solutions using the BOMBARDIER FLEXITY tram as an example.

Energy storage enables better utilisation of a tram’s braking energy2, even if catenary free operation is only partially used to generate energy cost savings and to relieve overworked sub-stations.

The first catenary free operation of a tram with integrated Lithium-Ion (Li-Ion) energy storage within the propulsion system of a BOMBARDIER1 FLEXITY 21 tram was carried out for the newly-built tram line of the Chinese metropolis of Nanjing. The trams have been in successful passenger operation since the Youth Olympic Games in August 2014, running without catenaries on 90% of the line.

Operational concept

The vehicles used in Nanjing are 5-segment low-floor FLEXITY 21 trams. Four of its six axles are powered by a single axle drive with asynchronous motors and a nominal power of 120 kW each.

The vehicles provide space for approximately 300 passengers and are designed for a maximum speed of 70km/h with initial acceleration of 1.2 m/s².

Recharging of the energy storage system is carried out via the tram’s pantograph. The charging can take place when the vehicle is stationary or while driving, giving the opportunity to optimise the CFO concept for all kinds of track profiles and enable high performance operation with travelling at high speeds, or running on demanding tracks.

The vehicles are in use on the newly-built Hexi line in the Chinese metropolis Nanjing. The track is 7.65km-long and has 13 stops; the recharging of the traction batteries takes place at the 13 stops as the sections between the stations are all catenary free. The catenary length within the stations is approximately 90m which leads to a CFO share of approximately 90%. The transition between catenary-free operation and catenary operation is performed automatically without any control assistance from the driver. For this purpose beacons (tags) are installed at the beginning and end of each catenary section.

The tags are installed in a way that allows best control of the pantograph by vehicle control, in order to optimise use of the catenary – directing its energy either for acceleration or to charge the traction battery. In catenary operation, traction will always have priority over the charging of the traction batteries. This ensures that there is no reduction of the tractive effort and thus no loss of acceleration due to line current limit.

Due to the automatic control of the pantograph lifting and lowering process, proper recharging of the traction batteries is ensured, enabling optimum battery life and ensuring reliable operation of the tram without an additional burden on the tram driver.

The tram driver, however, maintains the ability to manually control the battery charging operation so that the vehicle can still run contrary to the usual driving direction or in case the beacon system fails.

Propulsion system

The topology is similar to that of a propulsion system with double layer capacitor energy storage3.

The energy storage (in this case a Li-Ion accumulator) is connected directly to the DC link of the motor converter via a bi-directional DC-DC-converter ‘ES-chopper’ leading to higher efficiency of the propulsion system. The auxiliary converters are supplied either directly from the catenary or, in case of catenary free operation, from the traction batteries via the DC link of the motor converters, ensuring that the vehicle can be started up in both operation modes. Furthermore, the efficiency of the system is improved since the current portion for the supply of the auxiliaries is not conducted via the filter inductor.

Since the depth of discharge (DoD) has a large impact on the wear of the traction battery, it must be ensured that the load of the traction batteries is balanced over the whole vehicle. Uneven balance would mean that the batteries with higher DoD would not achieve their calculated life time which could not be tolerated. However, there are always small deviations in the load of the drive system due to differences in the driving resistance at the axle, or tolerances of the components. These load deviations would then lead to a drifting apart of the traction battery DoDs. All drive systems and all traction batteries are coupled by the DC busbar. This coupling is used to equalise the load of the traction batteries by means of a balancing control. In addition, this coupling increases availability of the drives in case of a traction battery failure.

FLEXITY 2 low-floor tram with energy storage system

Transition

The transition between catenary operation and catenary free operation takes place without any limitation of traction and even with full charging current. Hence, measures to avoid arcing during raising or lowering of the pantograph are required. To avoid arcing, the vehicle input current through the pantograph needs to be zero at the moment the contact strip loses contact to the overhead line. When raising the pantograph, a charging current surge from balancing of the DC link voltage to the catenary voltage must be avoided.

For this purpose the DC link voltage is increased by the ES-chopper to a voltage level which is above the voltage of the catenary. By increasing the DC link voltage the current taken from the catenary lowers to zero. At the same time the discharging current from the traction battery increases proportionally. Due to this, the required power to accelerate the vehicle is taken over in a smooth transition from the catenary to the traction battery. Hence there is no jerk or reduction of the tractive effort. As soon as the loss of contact of pantograph to the catenary has been detected, the DC link voltage is decreased to a lower level and the transition to catenary free operation is complete.

Passenger operation

The trams have been in successful passenger operation since the Youth Olympic Games of Nanjing in August 2014. By February 2016 the six vehicles in operation reached a mileage of 350tkm without any severe malfunctions or breakdowns. The load of the traction batteries is well balanced and the traction battery is periodically recharged in the stations.

With a prototype vehicle (using the same energy storage) a long distance test run in CFO has been performed without passengers but within the regular tram network in the German city of Mannheim. By the end, the vehicle reached a distance of 41.6km (average speed 24.7km/h) only driven by traction batteries. Of course, this operation is not realistic for daily operation but it shows that the system provides a reserve so a breakdown of vehicle is quite unlikely even in the case of a disturbance (e.g. traffic jam or accident) of the operation.

Conclusion

The integration of Li-Ion energy storage can improve the efficiency of trams. With catenary free operation it is possible to use an effective and environmentally-friendly mode of transport without damaging the landscape of a city. The recharging of the traction batteries is performed fully automatically without any control action required by the driver. During the transition, full performance of the propulsion is ensured; hence the transition is carried out safely and comfortably without any interruption of the driving/braking force. With the opportunity of dynamic and static recharging of the energy storage, the system can be optimised for different track profiles and enables high performance operation with high travel speeds and demanding tracks. The presented operational concept has proven successful with the vehicles in passenger operation since August 2014, illustrating their capability and reliability.

References

  1. BOMBARDIER and FLEXITY 2 are trademarks of Bombardier Inc. or its subsidiaries
  2. Klohr, M., Beek, M.: RNV und der MITRAC Energy Saver – ein Erfahrungsbericht, SFT, Graz 2013
  3. Fröhlich, M., Klohr, M., Rost, J.: Energy Storage on Board of Railway Vehicle, PCIM, Nuremberg 2010.

Biography

Frank Becker studied Electrical Engineering at the Karlsruhe Institute of Technology (former University Karlsruhe) followed by a PhD. Frank has been a System Engineer in the Propulsion & Controls Division at Bombardier Transportation since 2011.
