New images show the progress made to the Elizabeth line above ground

14
SHARES

Posted: 9 August 2017 | | No comments yet

New images released by Crossrail highlight the construction progress that has been made above ground for the Elizabeth line.

New images show the progress made to the Elizabeth line above ground

Public roof garden above Canary Wharf station

The photographs highlight construction progress above ground with the exteriors of the new stations and railway structures including:

  • Paddington: construction has started on the 120 metre long glazed canopy that will let natural light reach the platforms 30 metres below
  • Tottenham Court Road: brick and stone finishes are being installed on the two separate buildings that have been built above the station on Dean Street
  • Durward Street head house: the bell-wave pattern on the cladding of the ventilation shaft reflects the historic Whitechapel bell foundries
  • Victoria Dock Portal head house: colourful architectural finish on the top of the ventilation and emergency access shaft near Custom House station
  • Woolwich: the size, colour and material of the brickwork that clads the station and ventilation buildings echo the masonry of the armories that once stood in the area
  • Abbey Wood: the new timber and glass entrance of the nearly-complete station being delivered by Network Rail.

New images show the progress made to the Elizabeth line above ground

Mile End shaft head house

New images show the progress made to the Elizabeth line above ground

Royal Victoria Dock head house

“Since construction began in 2009, much of the work for the Elizabeth line has mostly taken place below ground,” said Simon Wright, Crossrail Programme Director. “The new stations and structures can now be seen rising upwards giving passengers a glimpse of their new railway that will open on time in December 2018.”

New images show the progress made to the Elizabeth line above ground

Stepney Green access shaft head house

New images show the progress made to the Elizabeth line above ground

Tottenham Court Road

New images show the progress made to the Elizabeth line above ground

Whitechapel station

When completed, the Crossrail’s route will pass through 40 stations from Reading and Heathrow in the west, through new twin-bore 21km tunnels to Shenfield and Abbey Wood in the east.
